Wave Generator 2

1 collaborator

Michael Novak (Author)

WHAT IS IT?

(a general understanding of what the model is trying to show or explain)

HOW IT WORKS

(what rules the agents use to create the overall behavior of the model)

HOW TO USE IT

(how to use the model, including a description of each of the items in the Interface tab)

THINGS TO NOTICE

(suggested things for the user to notice while running the model)

THINGS TO TRY

(suggested things for the user to try to do (move sliders, switches, etc.) with the model)

EXTENDING THE MODEL

(suggested things to add or change in the Code tab to make the model more complicated, detailed, accurate, etc.)

NETLOGO FEATURES

(interesting or unusual features of NetLogo that the model uses, particularly in the Code tab; or where workarounds were needed for missing features)

RELATED MODELS

(models in the NetLogo Models Library and elsewhere which are of related interest)

CREDITS AND REFERENCES

(a reference to the model's URL on the web if it has one, as well as any other necessary credits, citations, and links)

Comments and Questions

Please start the discussion about this model! (You'll first need to log in.)

Click to Run Model

globals [
  frequency-change-up
  volume-change-up
 frequency-change-down
  volume-change-down
  new-f-value
 new-v-value
]

to setup
  clear-all
  set new-f-value -1
  set new-v-value -1
end

to go
  if new-f-value != frequency or new-v-value != volume [update-all-plots]
end

to update-all-plots
  update-this-plot "Graph 1" 1
  update-this-plot "Graph 2" .1
  update-this-plot "Graph 3" .01
  update-this-plot "Graph 4" .001
  set new-f-value frequency
  set new-v-value volume
end

to update-this-plot [graph-name x-delta]
   let x-counter 0
  set-current-plot graph-name
  clear-plot
  draw-grid x-delta
  repeat 3999 [
    plotxy x-counter (20 + (volume / 100) * (9 * sin ((x-counter * 1 * frequency) *  360)))
    if graph-name = "Graph 1" and frequency > 1000 [
       plotxy x-counter (20 + 9)
       plotxy x-counter (20 - 9)
    ]
    set x-counter x-counter + (x-delta / 4000)
  ]
end

to draw-grid [x-delta]
  set-current-plot-pen "grid"
  let y-increment 15
  let x-increment 0
  repeat 3 [
    plotxy x-delta y-increment
    plot-pen-down
    plotxy 0 y-increment
    plotxy x-delta y-increment
    set y-increment y-increment + 5
    plot-pen-up
  ]
  repeat 9 [
    plotxy x-increment 10.01
    plot-pen-down
    plotxy x-increment 10.01
    plotxy x-increment 29.99
    set x-increment x-increment + (x-delta / 10)
    plot-pen-up
  ]
  set-current-plot-pen "default"
  set-plot-pen-color black
end

to more-frequency-up-one
  if frequency < 1000 [
  set frequency frequency + 1
  ]
  set frequency-change-up false
end

to more-volume-up-one
  if volume < 100 [
  set volume  volume + 1
  ]
  set volume-change-up false
end

to less-volume-down-one
  if volume > 0 [
  set volume  volume - 1
  ]
  set frequency-change-down false
end

to less-frequency-down-one
  if frequency > 0 [
  set frequency  frequency - 1
  ]
  set volume-change-down false
end

to more-frequency-double
  if frequency <= 500 [
  set frequency (frequency * 2)
  ]
  set frequency-change-up false
end

to less-frequency-half
  if frequency >= 2 [
  set frequency round (frequency * 0.5)
  ]
  set volume-change-down false
end

to more-volume-double
  if volume <= 500 [
  set volume (volume * 2)
  ]
  set frequency-change-up false
end

to less-volume-half
  if volume <= 2 [
  set volume round (volume * 0.5)
  ]
  set volume-change-down false
end
