Social Change Hamilton 1851-1861

Do you have questions or comments about this model? Ask them here! (You'll first need to log in.)

WHAT IS IT?

This model attempts to simulate a socio-economic structure observed by Michael B. Katz in his 1975 book, "The People of Hamilton, Canada West: Family and Class in a Mid-Nineteenth-Century City". In the book, he discusses how assessment rolls, city directories and other documents from 1851-1861 reflect two key dynamics: inequality and transience. The wealthy, established class of 1%-10% of the population stays largely the same, including the social institutions and structures of the city. The lower class, however, has high turn-over, low economic growth, and low property ownership. As with the original "Sugarscape" models and the secondary "Wealth Distribution" model, this adaptation attempts to set initial conditions that begin with disparity and, amid the dynamics of life, death, and economic activity, leave the economic gap largely unchanged. This is expressed in a near constant Gini index with significant lower class turnover, including possible movement with in the lower economic order but very little entry into the upper class.

Does lower class volatility / transience prevent social resources from growing? Does this impair solidarity? Do the wealthy get both more money and more social resources in the form of stability and institutional continuity, etc. It seems likely that these types of dynamics lead to mutual reinforcement.

The wealthy have dynamic stability which is likely a function of the social continuity noted above - both personal networks and institutional enrichment.

WHAT I NEED HELP WITH

I've been adapting the model but need help with the following:

1. It seems the split between the classes should be more clear with a probability function of some kind determining how likely it is that upper-class would move down and lower-class would move up. Maybe this isn't an important dynamic and can be excluded.

2. The split between classes should somehow record stability - ie. wealthy stay put, stay wealthy, while the lower class is more turbulent internally and in terms of movement in and out of the system. Katz research suggess as many as 2/3 of the population of 14,000 may have experienced moving in out betweeen 1851-1861. That transience takes the form of being in the assessment rolls at one point and then not thereafter. * Perhaps the classes could have different death rates to stand in for the higher transience of the lower classes. This may be easier than trying to design a spatially transient characteristic into the lower class.

3. It would be useful to add a social relation function visible in the form of ties so that the wealthy would have strong, bonding ties with few bridging ties to the lower class. The lower class would have small numbers of close ties (as in a family arrangement of some kind - transience was not a solitary male type but included whole families), fewer ties within the lower class, and many fewer with the upper class.

4. The wealthy would have a much better economic patch (or patches) to begin with and those patches would remain so. Perhaps a patch that is economically high remains fixed proportional to its value and has the potential to disappear or degrade in proportion with its lower value.

5. The image of the wealthy is something like a cluster of stable pillars of concrete that the lower class flows between and around. That doesn't quite get it because the water and concrete are two mutually exclusive materials whereas the wealthy and lower class are the same entities but with very different ranges of possibility. The feeling may be as exclusive as water flowing around concrete but the dynamic needs to be different than a straight flow model.

HOW IT WORKS

What follows is an adaptation of the original "Wealth Distribution" model. Money is used instead of grain. Each patch has some economic value in terms of money and an ability to generate more. Citizens get money from their patch but also use some up to live. The more money they keep, the wealthier a citizen gets.

The model begins with a roughly equal wealth distribution. THIS MAY NEED TO BE CHANGED AS A CITY DOES NOT BEGIN THIS WAY AND WEALTH WAS NOT DISTRIBUTED EQUALLY IN 1851 HAMILTON.

The citizens are mobile and can move around. They are trying to earn money and makes a decision about where to go based on the best opportunities they can see. They keep doing this until they die of old age [ ] or they run out of money and die of depravation [ ]. What they leave behind is an offspring. CHANGE IS NEEDED SO THAT WEALTH AND CHARACTERISTICS ARE PASSED TO THE OFFSPRING WITH PERHAPS A SMALL RANDOM VARIATION. IT IS IMPORTANT THAT LACK OR SURPLUS IS PASSED ALONG.

To observe the equity (or the inequity) of the distribution of wealth, a graphical tool called the Lorenz curve is utilized. The population is ranked by their wealth (as a percentage) and the percentage of the population that wealth represents (e.g. 30% of the wealth is owned by 50% of the population). The scales on the axes range from 0% to 100%.

A 45 degree angle means 30% or people have 30% of wealth, 90% have 90% of the wealth, and so on. In an extreme case, one person (1%) could have all the money (100%) in which case the curve would look like an "L" but backwards. This is expressed in the Gini coefficient by a "0" if wealth is equally distributed and "1" if one person has all the wealth - the bigger the value, the more unequal it is.

(0) Communist idealism <---------------> Hyper wealthy (1)

HOW TO USE IT

The NUM-PEOPLE slider controls size of initial population and limits can be set in code. The LIFE-EXPECTANCY-MAX slider is the oldest a citizen can be (number of ticks). The LIFE-EXPECTANCY-MIN slider is the earliest point at which a citizen can die (fewest ticks). The PERCENT-MOST-MONEY slider says how many citizens initially can have maximum wealth. The MONEY-GROWTH-INTERVAL is a probability for how often economic opportunity occurs on a patch. The NUM-MONEY-GROWN slider determines how big new economic opportunities are. The MAX-OPPORTUNITY slider determines how good far beyond their own patch a citizen can see. The SPENDING-MAX is the maximum amount a citizen can spend in one time interval.

EXPERIMENTAL OBSERVATIONS

Settings of 1/3 of most, between 1/3 - 2/3 and greater than 2/3

1. When the diffusion values are changed (ranging from 0.10 - 0.99) very little changes.
2. If initial diffusion and "spread it around some more" are highly contrasted very little changes (eg. 0.10 initial and 0.90 spread around some more).
3. Maximum economic foresight makes for a more volatile balance of high - mid - low income
4. When spending limit is very low, classes are closer to each other.
5. When spending is middle level, the high - low divide is more evident.
6. When spending is high, the high - low divide is evident.
7. The divides are very persistent across all variables.
8. When the spending, opportunity, etc. are lowest, the have / have-not divide is most striking. 9.It is really tough to change the divide much - to a degree, yes but in any fundamental way, no.

Settings of 1/5 of most, between 1/5 - 4/5 and greater than 4/5

• Not much notable change

Settings of 1/10 of most, between 1/10 - 9/10 and greater than 9/10

• With mid-point settings, a very low number of wealth with anlargely equal mid and low pattern emerges.

Settings of max-wealth * (0.90) for red and max-wealth * (0.10) for green

• Yields a significant number of poor and very few rich and middle income.

NETLOGO FEATURES

Examine how the landscape of color is created --- note the use of the scale-color reporter. Each patch is given a value, and scale-color reports a color for each patch that is scaled according to its value.

Note the use of lists in drawing the Lorenz Curve and computing the Gini index.

CREDITS AND REFERENCES

This original model is based on a model described in Epstein, J. & Axtell R. (1996). Growing Artificial Societies: Social Science from the Bottom Up. Washington, DC: Brookings Institution Press.

For an explanation of Pareto's Law, see http://www.xrefer.com/entry/445978.

For more on the calculation of the Gini index see:

• Deltas, George (2003). The Small-Sample Bias of the Gini Coefficient: Results and Implications for Empirical Research. The Review of Economics and Statistics, February 2003, 85(1): 226-234.

In particular, note that if one is calculating the Gini index of a sample for the purpose of estimating the value for a larger population, a small correction factor to the method used here may be needed for small samples.

HOW TO CITE

If you mention this model in a publication, we ask that you include these citations for the model itself and for the NetLogo software:

• Wilensky, U. (1998). NetLogo Wealth Distribution model. http://ccl.northwestern.edu/netlogo/models/WealthDistribution. Center for Connected Learning and Computer-Based Modeling, Northwestern University, Evanston, IL.
• Wilensky, U. (1999). NetLogo. http://ccl.northwestern.edu/netlogo/. Center for Connected Learning and Computer-Based Modeling, Northwestern University, Evanston, IL.

COPYRIGHT AND LICENSE

This version of the model: Non-commercial. Copyright Milton Friesen, ingenuityarts@gmail.com, August 2017

Original copyright 1998 Uri Wilensky.

This work is licensed under the Creative Commons Attribution-NonCommercial-ShareAlike 3.0 License. To view a copy of this license, visit http://creativecommons.org/licenses/by-nc-sa/3.0/ or send a letter to Creative Commons, 559 Nathan Abbott Way, Stanford, California 94305, USA.

Commercial licenses are also available. To inquire about commercial licenses, please contact Uri Wilensky at uri@northwestern.edu.

The "Wealth Distribution" original model was created as part of the project: CONNECTED MATHEMATICS: MAKING SENSE OF COMPLEX PHENOMENA THROUGH BUILDING OBJECT-BASED PARALLEL MODELS (OBPML). The project gratefully acknowledges the support of the National Science Foundation (Applications of Advanced Technologies Program) -- grant numbers RED #9552950 and REC #9632612.

The original model was converted to NetLogo as part of the projects: PARTICIPATORY SIMULATIONS: NETWORK-BASED DESIGN FOR SYSTEMS LEARNING IN CLASSROOMS and/or INTEGRATED SIMULATION AND MODELING ENVIRONMENT. The project gratefully acknowledges the support of the National Science Foundation (REPP & ROLE programs) -- grant numbers REC #9814682 and REC-0126227. Converted from StarLogoT to NetLogo, 2001.
