bark beetle epidemic

;; Bark beetle epidemic model.
;;
;; Coded in 2017 by Lin Xiang; Last revised in 2021 by Lin Xiang (lxiang75@gmail.com; lin.xiang@uky.edu)

; lxiang75@gmail.com ; lin.xiang@uky.edu
;;
;; If you mention this model in a publication, we ask that you include the citations below.
;;
;; Xiang, L. (2017). Bark Beetle Epidemic. Zoology Department, Weber State University, Ogden, UT.
;;
;;-----------------------------------------
;;CREATIVE COMMONS LICENSE
;;This code is distributed by Lin Xiang under a Creative Commons License:
;;Attribution-ShareAlike 4.0 International (CC BY-SA 4.0)
;;https://creativecommons.org/licenses/by-sa/4.0/
;;
;;-----------------------------------------


breed[spruces spruce]
breed[d-trees d-tree]
breed[beetles beetle]


beetles-own[age]
patches-own[hit]
globals [num-beetles dead-trees total-dead-trees]


;================================

to setup
  ca

  setup-patches

  ask patches
  [let tree-1 count spruces-here                                           ;find number of spruce trees
    let tree-2 count d-trees-here                                          ;find number of other trees
     if tree-1 = 0 and tree-2 = 0
      [ifelse random 100 < (100 - %-of-non-spruce-trees)
        [sprout-spruces 1                                                  ;find number of spruce trees
          [set shape "2spruce"
            set size 2.25 - random-float 2.25                                                  ;spruce tree size
            set color rgb 0 110 0
            setxy pxcor + random-float 0.5 pycor + random-float 0.5        ;sightly randomize spruce tree positions
            ]]
         [sprout-d-trees 1
          [set shape "tree2"
            set size 1.5
            set color rgb 0 90 0
            setxy pxcor + random-float 0.5 pycor + random-float 0.5
            ]]
         ]]

  create-beetles 150
  [setup-beetles]

  ifelse count beetles > 0 [set num-beetles count beetles][set num-beetles "There are no bark beetles in this forest."]

  reset-ticks
end
;================================

to setup-d-trees-seedling
            set shape "tree2"
            set size 0.25
            set color rgb 0 85 0
            setxy pxcor + random-float 0.5 pycor + random-float 0.5
end

to setup-spruces-seedling
   set shape "2spruce"
            set size 0.25
            set color rgb 0 110 0
            setxy pxcor + random-float 0.5 pycor + random-float 0.5 ;slightly randomize the tree position. This makes the forest look more natural but increase the max number of trees in a the simuation as each patch can have more than one trees.
end

to setup-beetles                         ; set up initial beetle features, in which all beetles are at the age of 0
    set color 1
    set shape "bark-beetle"
    set size 0.3
    ;setxy (random-float 3)(random-float 3)
    setxy (random-xcor)(random-ycor)
    set age 0
end

to setup-patches                                           ;set patches to certain drought level
  ask patches [
    set pcolor 36.5 + random-float (0.5 + (0.5 * Severity-of-Drought))
    ]
end

;=================================

to go

  ;if count beetles = 0 [set num-beetles "There are no bark beetles in this forest." stop]

  ifelse count beetles > 0 [set num-beetles count beetles][set num-beetles "There are no bark beetles in this forest." stop]

  tree-grow
  infest
  patch-count
  set-tree-color
  beetle-migrate
  temperature-control
  beetle-death
  seedling
  count-dead-trees

  tick
end


;==================================

to tree-grow                                  ; Spruces grow until size 2.25
  ask spruces
  [if size < 2.25 [set size size + 0.05]]
  ask d-trees
  [if size < 1.5 [set size size + 0.025]]
end

to infest                                      ;Beetles detect trees avaiable in radius of 1.5. then migrate to one of the available spruces.
  ask beetles
     [let target-tree one-of spruces with [size > 0.5] in-radius 1.5     ;infest tree larger than 0.5
  ifelse target-tree != nobody
    [move-to target-tree
       hatch 2 [set age 0]                  ;If a beetle infests a mature tree, hatches 2 offspring and then dies.
          if random 100 < Temperature-increase * 2 [hatch 1 [set age 0]] ;If temperature increases, hatch one more beetle at the defined rate.
          die
        ]
    [ set age age + 1]                      ;If a beetle does not infests a mature tree, age increases 1
  ]
end

to patch-count                                ;count how many beetles on a patch, use the number of beetles to indicate severity of infestation
  ask patches
  [set hit 0
    let num-bug count beetles-here
    set hit (num-bug * (10 + (Severity-of-Drought * 5)))]
end

to set-tree-color                            ;determine severity of infestation. The number of beetles are associated to the tree color
  ask spruces
  [let redness [hit] of patch-here
    ifelse redness > 200
    [set dead-trees dead-trees + 1 die]
    [set color rgb redness 110 0]
  ]
end

to seedling                                  ;seed new green trees at 5 percentage. the higher the seedling rate, the less likely the beetle population crashes.
  ask patches
  [let tree-1 count spruces-here
    let tree-2 count d-trees-here
     if tree-1 = 0 and tree-2 = 0
     [if random 1000 < 50
     [let tree-ratio count spruces / (count spruces + count d-trees + 1)
     ifelse tree-ratio * 100 < (100 - %-of-non-spruce-trees)
        [sprout-spruces 1
          [setup-spruces-seedling]]
        [sprout-d-trees 1
          [setup-d-trees-seedling]]
      ]]]

  if (100 - %-of-non-spruce-trees) = 100 [ask d-trees [die]]        ;clear other tree when diversity is low
end

to beetle-death
  ask beetles with [age >= 2] [die]           ;If beetles with age of 2 or older die.
end

to temperature-control                             ;Percentages of beetles die every year, related to the temperature increase.
  ask beetles
  [if random 100 > ((Temperature-increase * 2) + 50)
    [die]]
end

to beetle-migrate
  ask beetles [
    rt random 360 fd 1 + random 3
    ]
end

to count-dead-trees
  set total-dead-trees dead-trees
  set dead-trees 0
end
